| Plaats van herkomst: | CHINA |
|---|---|
| Merknaam: | Bozhong |
| Certificering: | IOS,SGS |
| Modelnummer: | SUS 347 |
| Min. bestelaantal: | 500KG |
| Verpakking Details: | Standaard Zeewaardig Pakket |
| Levertijd: | 7-25DAYS VOLGENS UW ORDEhoeveelheid |
| Betalingscondities: | T/T, L/C |
| Levering vermogen: | 1000 TON PER MAAND |
| Modelleer nr.: | 347 | Speciaal Gebruik: | Het meten van Hulpmiddelen, Snijders in Gemeenschappelijk Staal |
|---|---|---|---|
| Oppervlakte: | 2b/Ba/No.4/Mill rand/Gescheurde Rand | Vorm: | Bladrollen/Stroken |
| Dikte: | 0.3~180mm Dikte | HS Code: | 7219220000 |
| Proces: | Koud/Warmgewalst | ||
| Markeren: | 1.4550 SS Staalplaat,347 SS Staalplaat |
||
SUS 347, 0Cr18Ni11Nb Stainless Steel Plates/Sheets 347 1.4550
This data sheet applies to stainless steel 347 / 1.4550 hot and cold rolled sheet, strip and bars, semi-finished products, rods and sections as well as for seamless and welded steel tubes for mechanical and general engineering purposes.
For construction parts which should be resistant to scaling up to about 1050°C and extensively inured to the effect of sulfurous gases, especially above 900°C, is very low.
| Element | % Present (in product form) |
|---|---|
| Carbon (C) | 0.08 |
| Silicon (Si) | 1.00 |
| Manganese (Mn) | 2.00 |
| Phosphorous (P) | 0.045 |
| Sulfur (S) | 0.015 |
| Chromium (Cr) | 17.00 - 19.00 |
| Nickel (Ni) | 9.00 - 12.00 |
| Niobium (Nb) | 10xC to 1.00 |
| Iron (Fe) | Balance |
| Product Form | ||||||||
|---|---|---|---|---|---|---|---|---|
| C | H | P | L | L | TW / TS | |||
| Thickness (mm) Max | 8 | 13.5 | 75 | 160 | 2502) | 60 | ||
| Yield Strength | Rp0.2 N/mm2 | 2203) | 2003) | 2003) | 2054) | 2056) | 2055) | |
| Rp1.0 N/mm2 | 2503) | 2403) | 2403) | 2404) | 2406) | 2405) | ||
| Tensile Strength | Rm N/mm2 | 520 - 7203) | 520 - 7203) | 500 - 7003) | 510 - 7404) | 510 - 7406) | 510 - 7405) | |
| Elongation min. in & | A1) %min (longitudinal) | - | - | - | 40 | - | 35 | |
| A1) %min (transverse) | 40 | 40 | 40 | - | 30 | 30 | ||
| Impact Energy (ISO-V) ≥ 10mm thick | Jmin (longitudinal) | - | 100 | 100 | 100 | - | 100 | |
| Jmin (transverse) | - | 60 | 60 | - | 60 | 60 | ||
| Density at 20°C kg/m3 | 7.9 | |
|---|---|---|
| Modulus of Elasticity kN/mm2 at | 20°C | 200 |
| 200°C | 186 | |
| 400°C | 172 | |
| 500°C | 165 | |
| Thermal Conductivity W/m K at 20°C | 15 | |
| Specific Thermal Capacity at 20°C J/kg K | 500 | |
| Electrical Resistivity at 20°C Ω mm2 /m | 0.73 | |
